Miro RGS11-100A RGS Series High-Speed Semiconductor Fuse, 100A, 250V
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Miro RGS11-100A is a professional-grade high-speed semiconductor protection fuse designed for the rapid isolation of faults in power electronic systems. Classified under the aR utilization category, this fuse is specifically optimized to safeguard sensitive components such as thyristors, diodes, and rectifiers in industrial converters, UPS systems, and motor drives. Its compact bolt-on design ensures superior electrical contact and mechanical stability in high-current industrial applications.
| Product ID (MPN) | RGS11-100A |
| Utilization Category | aR (High-Speed Semiconductor Protection) |
| Rated Voltage | 250V |
| Rated Current | 100A |
| Fixing Center (B) | 42 mm |
| Total Length (C) | 56 mm |
| Body Diameter (φD) | 16.5 mm |
| Blade Width (E) | 12.5 mm |
| Mounting Hole (φd) | 6.5 x 9 mm |
| Industry Equivalents | CR2L, GSB |
