Miro RGS11-125A RGS Series High-Speed Semiconductor Fuse, 125A, 250V
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Miro RGS11-125A is a high-speed semiconductor protection fuse specifically designed for ultra-fast fault isolation in power electronics. Belonging to the aR utilization category, this 125A fuse is engineered to protect sensitive components such as thyristors, diodes, and rectifiers in converters, motor drives, and battery protection systems. Its bolt-on blade construction ensures a reliable, low-resistance connection for high-current industrial applications.
| Product ID (MPN) | RGS11-125A |
| Utilization Category | aR (High-Speed) |
| Rated Voltage | 250V |
| Rated Current | 125A |
| Fixing Center (B) | 42 mm |
| Total Length (C) | 56 mm |
| Body Diameter (φD) | 16.5 mm |
| Blade Width (E) | 12.5 mm |
| Mounting Hole (φd) | 6.5 x 9 mm |
| Equivalent Types | CR2L, GSB |
