Miro RGS11-160A RGS Series High-Speed Semiconductor Fuse, 160A, 250V
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Miro RGS11-160A is a professional-grade high-speed semiconductor protection fuse designed for the ultra-fast interruption of short-circuit faults in power electronic systems. Classified under the aR utilization category, this 160A fuse is engineered to safeguard sensitive components such as thyristors, diodes, and rectifiers in industrial converters, motor drives, and battery systems, ensuring maximum protection for high-value power semiconductor modules.
| Product ID (MPN) | RGS11-160A |
| Utilization Category | aR (High-Speed Semiconductor Protection) |
| Rated Voltage | 250V |
| Rated Current | 160A |
| Fixing Center (B) | 42 mm |
| Total Length (C) | 56 mm |
| Body Diameter (φD) | 16.5 mm |
| Blade Width (E) | 12.5 mm |
| Mounting Hole (φd) | 6.5 x 9 mm |
| Equivalent Types | CR2L, GSB |
