Miro RGS11-16A RGS Series High-Speed Semiconductor Fuse, 16A, 250V
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Miro RGS11-16A is a high-speed semiconductor protection fuse specifically engineered for the ultra-fast interruption of short-circuit currents. Characterized by its aR utilization category, this fuse is optimized to protect power electronic components such as thyristors, rectifiers, and IGBT modules in industrial power converters and motor control applications. Its bolt-on blade design ensures a low-resistance contact and high mechanical stability under demanding operational conditions.
| Product ID (MPN) | RGS11-16A |
| Utilization Category | aR (High-Speed Semiconductor Protection) |
| Rated Voltage | 250V |
| Rated Current | 16A |
| Fixing Center (B) | 42 mm |
| Total Length (C) | 56 mm |
| Body Diameter (φD) | 16.5 mm |
| Blade Width (E) | 12.5 mm |
| Mounting Hole (φd) | 6.5 x 9 mm |
| Cross-Reference Equivalents | CR2L, GSB |
