Miro RGS11-20A RGS Series High-Speed Semiconductor Fuse, 20A, 250V
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Miro RGS11-20A is a professional-grade high-speed semiconductor protection fuse designed for the ultra-fast mitigation of short-circuit events in power electronic systems. Classified under the aR utilization category, this fuse is specifically engineered to safeguard sensitive components such as thyristors, diodes, and rectifiers in industrial converters, UPS systems, and motor drives, ensuring high-speed interruption and reliable equipment protection.
| Product ID (MPN) | RGS11-20A |
| Utilization Category | aR (High-Speed Semiconductor Protection) |
| Rated Voltage | 250V |
| Rated Current | 20A |
| Fixing Center (B) | 42 mm |
| Total Length (C) | 56 mm |
| Body Diameter (φD) | 16.5 mm |
| Blade Width (E) | 12.5 mm |
| Mounting Hole (φd) | 6.5 x 9 mm |
| Cross-Reference Equivalents | CR2L, GSB |
