Miro RGS11-25A RGS Series High-Speed Semiconductor Fuse, 25A, 250V
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Miro RGS11-25A is a high-performance semiconductor protection fuse (class aR) engineered for the rapid isolation of faults in power electronic circuits. This industrial-grade fuse is specifically optimized to protect sensitive semiconductor devices, including thyristors, diodes, and SCRs, in applications ranging from DC drives to power rectifiers. Its robust bolt-on construction provides superior electrical contact and mechanical reliability in high-vibration environments.
| Product ID (MPN) | RGS11-25A |
| Utilization Category | aR (High-Speed Semiconductor Protection) |
| Rated Voltage | 250V |
| Rated Current | 25A |
| Fixing Center (B) | 42 mm |
| Total Length (C) | 56 mm |
| Body Diameter (φD) | 16.5 mm |
| Blade Width (E) | 12.5 mm |
| Mounting Hole (φd) | 6.5 x 9 mm |
| Equivalent Types | CR2L, GSB |
