Miro RGS11-30A RGS Series High-Speed Semiconductor Fuse, 30A, 250V
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Miro RGS11-30A is a precision-engineered high-speed semiconductor protection fuse designed for the rapid isolation of faults in power electronic systems. Belonging to the aR utilization category, this fuse is optimized to protect sensitive components including thyristors, rectifiers, and high-power diodes. Its bolt-on blade design ensures high mechanical stability and low-resistance electrical contact in industrial power converters and motor drives.
| Product ID (MPN) | RGS11-30A |
| Utilization Category | aR (High-Speed) |
| Rated Voltage | 250V |
| Rated Current | 30A |
| Fixing Center (B) | 42 mm |
| Total Length (C) | 56 mm |
| Body Diameter (φD) | 16.5 mm |
| Blade Width (E) | 12.5 mm |
| Mounting Hole (φd) | 6.5 x 9 mm |
| Equivalent Types | CR2L, GSB |
