Miro RGS11-40A RGS Series High-Speed Semiconductor Fuse, 40A, 250V
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Miro RGS11-40A is a professional-grade high-speed semiconductor protection fuse engineered for the ultra-fast interruption of short-circuit faults. Belonging to the aR utilization category, this fuse is specifically optimized for safeguarding power electronic components such as thyristors, diodes, and rectifiers in industrial power converters, motor drives, and UPS systems. Its bolt-on design ensures superior mechanical stability and low-resistance electrical contact in high-demand enterprise environments.
| Product ID (MPN) | RGS11-40A |
| Article No | 0507 |
| Utilization Category | aR (High-Speed Semiconductor Protection) |
| Rated Voltage | 250V |
| Rated Current | 40A |
| Fixing Center (B) | 42 mm |
| Total Length (C) | 56 mm |
| Body Diameter (φD) | 16.5 mm |
| Blade Width (E) | 12.5 mm |
| Mounting Hole (φd) | 6.5 x 9 mm |
| Industry Cross-Reference | CR2L, GSB |
