Mitsubishi Electric FR-D720-0.1K / FRD72001K FREQROL FR-D700 Variable Frequency Drive (VFD), 3-Phase 200-240VAC, 0.1kW (1/8HP)
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Mitsubishi Electric FR-D720-0.1K (equivalent order code FRD72001K) is a highly reliable micro-drive Variable Frequency Drive (VFD) engineered for precision control of 3-phase fractional horsepower motors. Delivering a 0.1kW (1/8HP) output with a versatile 0.2-400 Hz frequency range, this FREQROL FR-D700 series inverter features built-in Modbus RTU communication over RS-485 for seamless integration into industrial control networks. Designed with advanced safety and durability embedded, it incorporates standard Safe Torque Off (STO) to meet EN ISO 13849-1 Category 3 and IEC61508 SIL2 PLd standards, making it the optimal solution for applications such as packaging machines, lifts, fans, pumps, and material transfer conveyors.
| Product ID (MPN) | FR-D720-0.1K |
| Order Code | FRD72001K |
| Brand | Mitsubishi Electric |
| Product Category | Variable Speed/Frequency Drive (VSD/VFD) / Inverter |
| Series | FREQROL FR-D700 |
| Input Voltage | 200-240 VAC (3-Phase / 3P) |
| Active Power Rating | 100W / 0.1kW / 1/8HP |
| Nominal Output Current | 0.8A |
| Overload Current Rating | 150% for 60s / 200% for 0.5s (Inverse-time characteristic) |
| Output Frequency Range | 0.2 - 400 Hz |
| Apparent Power (S) | 0.3 kVA |
| Communication Protocol | Modbus RTU (via RS-485 Computer Link) |
| Digital Inputs | 5 x Source/Sink (STF, STR, RH, RM, RL), 2 x Safe Stop Channel (SS1) |
| Digital Outputs | 1 x SPDT Relay, 1 x Open Collector, 1 x PTO Pulse Train, 1 x SO Safety Monitor |
| Analog Inputs | 1 x (0-5Vdc / 0-10Vdc), 1 x (0-5Vdc / 0-10Vdc / 4-20mA) |
| Control Methods | Soft-PWM control, High carrier frequency PWM control, Optimum excitation control |
| Cooling Mechanism | Heatsink cooling |
| Protection Rating | IP20 |
| Compliance Standards | EN ISO 13849-1 Category 3, EN62061, IEC61508 SIL2 PLd |
