Mitsubishi Electric FR-D720-0.2K / 217400 FR-D700 Series Compact Inverter, 3-Phase 200-240V AC, 0.2kW (1.4A)
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Mitsubishi Electric FR-D720-0.2K (Order Code: 217400) is a highly reliable compact inverter from the FR-D700 series, engineered for precise induction motor control in industrial automation operations. Operating on a 3-phase 200-240V AC supply, it provides a 0.2kW rated motor capacity (1.4A output) and integrates advanced Magnetic Flux Vector Control. Built-in Safe Torque Off (STO) enhances functional safety, while native Modbus-RTU over RS-485 ensures seamless network integration. Designed with space-saving IP20 housing and resilient spring clamp terminals, this drive maximizes panel space and minimizes installation time for enterprise applications.
| Product ID (MPN) | FR-D720-0.2K |
| Order Code | 217400 |
| Product Type | Compact Inverter |
| Rated Voltage | 200 - 240 V AC |
| Phases | 3 |
| Rated Motor Capacity (ND) | 0.2 kW |
| Rated Output Current (ND) | 1.4 A |
| Control Method | Magnetic Flux Vector / Soft-PWM / V/F Control |
| Safe Torque Off (STO) | Yes |
| Display | Built-In (4 Digits LED) |
| Integrated Digital I/O | 5 Inputs / 2 Outputs (1 Transistor, 1 Relay) |
| Integrated Analogue I/O | 2 Inputs / 1 Output |
| Built-In Network Protocol | Modbus-RTU (RS-485) |
| Terminal Block Type | Spring Clamp |
| Power Loss (ND) | 20 W |
| Protection Class | IP20 |
| Dimensions (W x H x D) | 68 x 128 x 80.5 mm |
| Weight | 0.5 kg |
| Conformity / Standards | CE, UL/cUL, EAC, UKCA, RoHS Compliant |
