Mitsubishi Electric FR-D720-1.5K / 217403 FR-D700 Series Compact Inverter, 3-Phase 200-240V AC, 1.5 kW, 7.0 A
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Mitsubishi Electric FR-D720-1.5K (Order Code: 217403) is a highly reliable compact inverter from the FR-D700 series, specifically engineered for the precise control of 3-phase AC induction motors. Rated for a motor capacity of 1.5 kW and an output current of 7.0 A, this variable frequency drive integrates advanced magnetic flux vector control, Safe Torque Off (STO) functionality, and Modbus-RTU capability for seamless network communication. Designed with a space-saving IP20 architecture, flexible spring clamp terminals, and a clear 4-digit LED onboard display, it ensures dependable performance and simplified deployment in a wide array of industrial machinery applications.
| Product ID (MPN) | FR-D720-1.5K |
| Order Code | 217403 |
| Product Series | FR-D700 Series |
| Device Type | Compact Inverter |
| Rated Motor Capacity (ND) | 1.5 kW |
| Rated Output Current (ND) | 7.0 A |
| Input Phases | 3-Phase |
| Rated Voltage | 200 - 240 V AC |
| Permissible Voltage Range | 170 - 264 V AC |
| Control Method | Magnetic Flux Vector Control / V/F Control |
| Motor Type | Induction Motor |
| Safe Torque Off (STO) | Yes |
| Brake Chopper ED | 30% |
| Display | Built-in 4-Digit LED |
| Built-In Network | Modbus-RTU |
| Integrated Digital Inputs | 5 |
| Digital Outputs | 1 (Transistor), 1 (Relay) |
| Analogue I/O | 2 Inputs, 1 Output |
| I/O Terminal Block Type | Spring Clamp |
| Power Loss (ND) | 80 W |
| Standby Power Consumption | 5.5 - 14 W |
| Protection Class | IP20 |
| Dimensions (W x H x D) | 108 mm x 128 mm x 135.5 mm |
| Weight | 1.4 kg |
