Mitsubishi Electric FR-D720-2.2K / FRD72022K FREQROL FR-D700 Series Variable Speed Drive, 3-Phase 200-240VAC, 2.2kW / 3HP, 10A
Regular price
$390.00 USD
Regular price
Sale price
$390.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Mitsubishi Electric FR-D720-2.2K (FREQROL FR-D700 series) is a robust and compact 3-phase Variable Speed Drive (VFD) engineered for precise motor control in demanding industrial environments. Delivering a 2.2kW (3HP) active power rating and a standard rated current of 10A, this inverter is designed to optimize the performance of pumps, fans, and machine tools. It features native Modbus RTU communication, versatile analog inputs, and critical hardware safety compliance (EN ISO 13849-1 Category 3, SIL2), making it a highly reliable solution for automated production lines and material handling equipment.
| Product ID (MPN) | FR-D720-2.2K |
| Order Code / Equivalent | FRD72022K |
| Product Series | FREQROL FR-D700 Series |
| Main Function | Variable Speed/Frequency Drive (VSD/VFD) / Inverter |
| Supply Voltage (AC) | 200Vac-240Vac (Nominal: 220Vac / 230Vac) |
| Type of Network | 3-Phase / 3P |
| Rated Active Power | 2.2 kW (3 HP) |
| Rated Apparent Power | 4 kVA |
| Rated Current | 10 A |
| Overload Capacity | 150% In for 60s / 200% In for 0.5s (inverse-time characteristic) |
| Network Frequency (Output) | 0.2-400 Hz |
| Communication Protocol | Modbus RTU (RS-485 Computer Link) |
| Analog Inputs | 1 x (0-5Vdc / 0-10Vdc); 1 x (0-5Vdc / 0-10Vdc / 4-20mA) |
| Key Control Functions | Soft-PWM, PID control, Optimum excitation control, Slip compensation, Frequency jump, Forward/reverse prevention |
| Degree of Protection | IP20 |
| Cooling Design | Forced Air Cooling |
| Compliance Standards | EN ISO 13849-1 Category 3, EN62061, IEC61508 SIL2 PLd |
| Application Types | Material Transfer, Lifts, Packaging, Machine Tools, Air Conditioning, Fans, Pumps |
