Mitsubishi Electric FR-D720-3.7K-60 / FRD72037K60 Micro VFD with Conformal Coating, 3-Phase 200-240VAC, 3.7kW / 5HP, 16.5A
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Mitsubishi Electric FR-D720-3.7K-60 (FREQROL FR-D700 series) is a highly reliable micro Variable Frequency Drive (VFD) designed for compact, high-performance automated systems. Rated for 3-phase 200-240V inputs, this inverter delivers 3.7kW (5HP) of motor capacity and 16.5A of rated current, utilizing Magnetic Flux Vector Control for precision torque management. As a specialized Japanese specification model, it features ruggedized printed circuit board conformal coating (IEC60721-3-3 3S2 3C2) for superior chemical and environmental resistance, alongside native RS-485 Modbus RTU communication, Safe Torque Off (STO), and spring clamp terminals for streamlined integration into harsh industrial environments.
| Product ID (MPN) | FR-D720-3.7K-60 |
| Order Code / Equivalent | FRD72037K60 (Base Material: 217415) |
| Product Series | FREQROL FR-D700 Compact Inverter |
| Main Function | Micro Variable Speed/Frequency Drive (VSD/VFD) |
| Special Features | Japanese Specification; Conformal Coating (Chemical Resistance) |
| Supply Voltage (AC) | 200Vac-240Vac (Minimum: 170V / Maximum: 264V) |
| Type of Network | 3-Phase / 3P |
| Rated Motor Capacity | 3.7 kW (5 HP) |
| Rated Output Current | 16.5 A (ND) |
| Network Frequency (Output) | 0.2 - 400 Hz |
| Power Loss | 160 W (Standby: 6-15 W) |
| Brake Chopper ED | 30% |
| Control Methods | Magnetic Flux Vector Control, Soft-PWM / High Frequency PWM, V/F Control |
| Communication Protocol | Built-In Modbus RTU (1x RS-485 port) |
| Integrated Interfaces | 5x Digital Inputs, 1x Transistor Output, 1x Relay Output, 2x Analogue Inputs, 1x Analogue Output |
| Terminal Block Type | Spring Clamp |
| Local Display | Built-in 4-Digits LED |
| Degree of Protection | IP20 (PCB Coating IEC60721-3-3 3S2 3C2) |
| Safety Functions | Safe Torque Off (STO) Integrated |
| Dimensions (W x H x D) | 170 mm x 128 mm x 142.5 mm |
| Weight | 1.8 kg |
