MITSUBISHI ELECTRIC FR-D720-5.5K / 217416 FR-D700 Series Compact Inverter, 5.5 kW, 3-Phase 200V
Regular price
$600.00 USD
Regular price
Sale price
$600.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Mitsubishi Electric FR-D720-5.5K (Order Code: 217416) is a robust 5.5 kW, 3-phase compact inverter from the highly reliable FR-D700 series. Designed with built-in magnetic flux vector control and native Modbus-RTU networking, it ensures precise motor management and effortless integration into industrial automation systems. Featuring reliable Safe Torque Off (STO) circuitry, spring clamp terminals, and an IP20-rated enclosure, this drive delivers dependable safety and scalable performance for enterprise motor applications.
| Product ID (MPN) | FR-D720-5.5K |
| Order Code | 217416 |
| Series | FR-D700 SERIES |
| Type | Compact Inverter |
| Current Type | AC |
| Phases | 3 |
| Minimum Rated Voltage | 200 V |
| Maximum Rated Voltage | 240 V |
| Rated Motor Capacity ND | 5.5 kW |
| Rated Output Current ND | 23.8 A |
| Control Method | Magnetic Flux Vector Control |
| Motor Type | Induction Motor |
| Safe Torque Off (STO) | YES |
| Integrated Digital Inputs | 5 |
| Integrated Analogue Inputs | 2 |
| IO Type of Terminal Block | Spring Clamp |
| Display Type | Built-In 4 Digits LED |
| Built-In Network | MODBUS-RTU |
| Protection Class | IP20 |
| Dimensions (W x H x D) | 220 x 150 x 155 mm |
| Weight | 3.6 kg |
