Mitsubishi Electric FX5S-40MT/ES MELSEC iQ-F FX5S Series PLC CPU Module, 24 Inputs, 16 Transistor (Sink) Outputs
Regular price
$300.00 USD
Regular price
Sale price
$300.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Mitsubishi Electric FX5S-40MT/ES is a high-performance, compact PLC CPU module belonging to the MELSEC iQ-F series. Designed for sophisticated industrial automation and machine control, this unit features 40 built-in I/O points and integrated Ethernet and USB communication ports, providing a robust solution for data-intensive manufacturing environments. Its versatile architecture supports seamless integration into modern enterprise networks while maintaining a small physical footprint.
| Product ID (MPN) | FX5S-40MT/ES |
| Rated Voltage | 100 to 240 V AC (+10%, -15%) |
| Power Consumption | 30 W |
| Service Power Supply | 24 V DC (400 mA capacity) |
| Total I/O Points | 40 Points |
| Input Specifications | 24 Inputs (24 V DC Sink/Source) |
| Output Specifications | 16 Outputs (Transistor / Sink) |
| Built-in Communication | Ethernet (10/100 Mbps), USB (Mini-B) |
| IP Address (Default) | 192.168.3.250 |
| Dimensions (W x H x D) | 130 x 90 x 83 mm |
| Mounting Method | DIN rail (35mm) or Direct Screw Mounting |
