MIRO NH00C 63A / RO30C / NT00C / RT16-00C NH00 Low Voltage Fuse Link, 63A, 500V/660V gL
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The MIRO NH00C 63A is a compact low voltage NH fuse link engineered for general industrial protection (gL/gG) in 500V/660V power distribution systems. Its size 00 (code 000) footprint and 63 A rated current make it an ideal choice for feeder and motor circuit overcurrent and short-circuit protection. Certified to IEC 60269-2-1, this fuse provides high breaking capacity and outstanding current limitation, ensuring long-term operational reliability.
| Product ID (MPN) | NH00C 63A |
| Order Code / Ref No | RO30C / NT00C / RT16-00C |
| Rated Voltage | 500 V AC / 660 V AC |
| Rated Current | 63 A |
| Fuse Characteristic | gL/gG (full‑range general protection) |
| Rated Breaking Capacity | 120 kA (500 V) / 50 kA (660 V) |
| Power Dissipation (at 63 A) | 4.5 W |
| Rated Frequency | 45 – 62 Hz |
| Size Code | 000 (NH00) |
| Overall Dimensions (L × W × H) | 78.5 mm × 35 mm × 49.5 mm (approx.) |
| Weight | 138 g |
| Blade Material | Silver‑plated copper |
| Body Material | High‑strength ceramic |
| Applicable Standards | IEC 60269‑2‑1, VDE 0636‑2 |
