Parker 321H35-2995-481865C2 2-Way Normally Closed Solenoid Valve, 1/2" Port, 24VDC
Regular price
$225.00 USD
Regular price
Sale price
$225.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Parker 2-Way Normally Closed, 1/2" General Purpose Solenoid Valve designed with a brass body. Suitable for air media, utilizing 24VDC input voltage. Sold as a single unit.
Key Features
- Body Material: Brass
- Voltage: 24VDC
- Seal Material: PUR
- Flow Coefficient: 3.6 m3/hour, 60 L/min
- Pressure Differential: 1.5 to 40 bar
- Coil Specifications: IP65
| Part Number | 321H35-2995-481865C2 |
| Body Material | Brass |
| Product Series | General Purpose Solenoid Valves |
| Voltage (V) | 24VDC |
| Valve Type | 2-Way |
| Function | Normally Closed (NC) |
| Port Size | 1/2 inch |
| Input Voltage | 24.0 VDC |
| Seal Material | PUR |
| Orifice 1 Size | 15 mm |
| Flow Coefficient 1 | 3.6 m3/hour, 60 L/min |
| Power (Watts) | 9 |
| Coil Type | Coil for DIN plug connection, 32 mm |
| Maximum Pressure Differential | 40 bar |
| Minimum Pressure Differential | 1.5 bar |
| Number of Ports | 2 |
| Actuation Type | Pilot Operated |
| Media | Air |
| Port Type | BSP |
| Coil Specifications Met | IP65 |
