HONGFA HFE82V-250C / HFE82V-300C Direct Current Relay, 250A / 300A, 1000VDC Max
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
HONGFA HFE82V-250C / HFE82V-300C are direct current relays with 1 Form A contacts, 250A or 300A contact ratings, and a maximum switching voltage of 1000VDC. Both models support 12VDC and 24VDC coil configurations with 6W coil power and use hermetically sealed ceramic-brazed construction.
| Models | HFE82V-250C / HFE82V-300C |
| Category | Direct Current Relay |
| HFE82V-250C Contact Rating | 250A |
| HFE82V-300C Contact Rating | 300A |
| Contact Arrangement | 1 Form A |
| Maximum Switching Voltage | 1000VDC |
| Coil Voltage Options | 12VDC / 24VDC |
| Coil Power | 6W |
| Mechanical Endurance | 2 × 10⁵ operations |
| Operate Time | ≤30ms |
| Release Time | ≤10ms |
| Ambient Temperature | -40°C to 85°C |
| Load Terminal Structure | M6 Screw Terminal Female |
Hongfa's ordering information identifies the HFE82V series configuration as intended for vehicle applications, with selectable load-voltage, coil-voltage, terminal, mounting, and coil configurations according to the complete ordering code.
For B2B sourcing, replacement, maintenance, or project BOM requirements, specify whether HFE82V-250C or HFE82V-300C is required together with the complete configuration code to ensure accurate electrical and mechanical matching.
For an RFQ, provide the required quantity, destination country, and complete HFE82V-250C or HFE82V-300C ordering code. Most qualified RFQs receive a response or quote within 12 hours.
