Schneider Electric CAD32FDC TeSys Deca Control Relay, 3 NO + 2 NC, 110 V DC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Schneider Electric CAD32FDC is a TeSys Deca control relay for control circuit applications. It provides a 3 NO + 2 NC contact configuration, operates with a 110 V DC control circuit voltage, and supports rated operational voltages up to 690 V AC.
| Brand | Schneider Electric |
| Manufacturer Part Number | CAD32FDC |
| Range | TeSys |
| Product Name | TeSys CAD, TeSys Deca |
| Product Type | Control relay |
| Device Short Name | CAD |
| Application | Control circuit |
| Utilisation Categories | DC-13, AC-14, AC-15 |
| Contact Configuration | 3 NO + 2 NC |
| Control Circuit Voltage | 110 V DC |
| Rated Operational Voltage | Up to 690 V AC, 25...400 Hz |
| Conventional Free Air Thermal Current | 10 A at 40 °C |
| Mechanical Durability | 30 Mcycles |
| Maximum Operating Rate | 180 cycles/min |
| Operating Time | 50...55 ms for coil energisation and NO closing |
| Control Voltage Limits | Operational: 0.7...1.25 Uc; drop-out: 0.1...0.25 Uc |
| Rated Making Capacity | 140 A AC and 250 A DC conforming to IEC 60947-5-1 |
| Short-Time Withstand Current | 100 A for 1 s; 120 A for 500 ms; 140 A for 100 ms |
| Associated Fuse Rating | 10 A gG conforming to IEC 60947-5-1 |
| Rated Insulation Voltage | 690 V conforming to IEC 60947-5-1 |
| Rated Impulse Withstand Voltage | 6 kV conforming to IEC 60947 |
| Minimum Switching Current | 5 mA |
| Switching Voltage | 17 V |
| Mounting | Plate or rail |
| Terminal Type | Screw clamp terminals |
| Tightening Torque | 1.7 N·m |
| Dimensions | 77 x 45 x 93 mm |
| Net Weight | 580 g |
Typical applications: Industrial control panels, machine control circuits, automation systems, interlocking circuits, and auxiliary switching functions requiring 3 NO + 2 NC contacts and a 110 V DC control supply.
Apexon Supply provides B2B sourcing and replacement support for Schneider Electric CAD32FDC. Verify the contact arrangement, control circuit voltage, operational voltage, mounting method, terminal configuration, and dimensional requirements before replacement.
Send the MPN, required quantity, and application requirements to request a B2B quote and technical alignment support.
