Schneider Electric Altivar ATV12HU15M2 VFD, 2 HP (1.5 kW), Single Phase 200-240V, with Heatsink
Regular price
$200.00 USD
Regular price
Sale price
$200.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview: The Schneider Electric ATV12HU15M2 is a compact, cabinet-mount variable speed drive (VSD) from the Altivar 12 series, designed for simple machine applications. It features a 1.5 kW (2 HP) output capacity for single-phase 200-240V power supplies and includes an integrated EMC filter and a heat sink with forced cooling. This drive offers basic control via Modbus communication and is suitable for applications requiring simple speed regulation.
Key Features:
- 1.5 kW (2 HP) motor power rating for single-phase 200-240V systems.
- Integrated EMC filter for basic electromagnetic compatibility.
- Modbus (RS485) communication via RJ45 connector for network integration.
- Compact cabinet-mount design with integrated heat sink, forced cooling, and IP20 protection rating.
- Basic I/O configuration: 4 discrete inputs, 2 discrete outputs, 1 analog input, 1 analog output, and 1 relay output.
- Motor control profiles include Voltage/Frequency (V/f), Sensorless Flux Vector control, and Quadratic V/f.
- Adjustable switching frequency from 2 to 16 kHz.
| Product ID / Article Code | ATV12HU15M2 |
| Brand | Schneider Electric |
| Series | Altivar 12 |
| Product Type | Variable Speed Drive (VSD) |
| Motor Power | 1.5 kW |
| Horse Power (HP) | 2 HP |
| Supply Voltage | 200...240 V AC |
| Supply Phases | 1 |
| Nominal Output Current | 7.5 A |
| Continuous Output Current (4kHz) | 7.5 A |
| Output Frequency Range | 0.5…400 Hz |
| Nominal Switching Frequency | 4 kHz |
| Switching Frequency Range | 2...16 kHz adjustable |
| Control Methods | Voltage/Frequency (V/f), Sensorless Flux Vector control, Quadratic V/f |
| Communication Protocol | Modbus (RS485) |
| EMC Filter | Integrated |
| Assembly Style | With heat sink (forced cooling) |
| Discrete Inputs | 4 |
| Discrete Outputs | 2 |
| Analog Inputs | 1 |
| Analog Outputs | 1 |
| Relay Outputs | 1 |
| Protection Rating (IP) | IP20 |
| Operating Temperature | -10…50 °C (14…122 °F) without derating |
| Storage Temperature | -25…70 °C (-13…158 °F) |
| Dimensions (W x H x D) | 105 x 142 x 156.2 mm (4.1 x 5.59 x 6.15 in) |
| Net Weight | 1.4 kg (3.09 lb) |
| Standards & Certifications | UL, CSA, CE, C-Tick, GOST, RCM, KC, IEC 61800 |
| Availability | Stock - Normally stocked |
