Schneider Electric Altivar ATV61HD18N4Z VFD, 25 HP (18.5 kW), 3-Phase 380-480V, 0.1-599Hz, Modbus, CANopen
Regular price
$1,800.00 USD
Regular price
Sale price
$1,800.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview: The Schneider Electric ATV61HD18N4Z is a discontinued variable speed drive (VSD) from the Altivar 61 series, designed for demanding pumping and ventilation applications. It delivers 18.5 kW (25 HP) of output power and is compatible with a 380-480V, 3-phase supply. This model offers advanced control including flux vector control without a sensor, a comprehensive suite of I/O, and supports a wide range of industrial communication protocols via optional cards.
Key Features:
- Motor Power: 18.5 kW / 25 HP (3-phase, 380...480V).
- Control Modes: Flux vector control without sensor, standard Voltage/Frequency ratio (2-point, 5-point, and Energy Saving quadratic U/f).
- Connectivity: Integrated CANopen and Modbus ports; expandable with optional cards for Profibus DP, EtherNet/IP, DeviceNet, and more.
- Safety Integration: Features Safe Torque Off (STO) functionality via the dedicated PWR safety input.
- Enclosure Rating: Standard IP20 (upper part), with options to achieve IP21, IP41, or IP54 using specific mounting kits.
- Product Status: Discontinued as of January 1, 2017, with service support available until October 28, 2025.
| Product ID / MPN | ATV61HD18N4Z |
| EAN / GTIN | 3389119205276 |
| Brand | Schneider Electric |
| Series | Altivar 61 |
| Product Type | Variable Speed Drive |
| Application | Pumping and Ventilation |
| Motor Power | 18.5 kW |
| Horsepower | 25 HP |
| Supply Voltage | 380...480 V AC |
| Supply Phases | 3 |
| Line Current | 37.5 A @ 480V; 45.5 A @ 380V |
| Continuous Output Current | 34 A @ 460V, 12 kHz; 41 A @ 380V, 12 kHz |
| Nominal Switching Frequency | 12 kHz |
| Switching Frequency Range | 1...16 kHz adjustable |
| Output Frequency Range | 0.1…599 Hz |
| Control Modes | Flux vector control without sensor, V/F (2 & 5 point, Quadratic, Energy Saving) |
| Analog Inputs | 2 (AI1: +/-10V; AI2: 0-20mA / 0-10V) |
| Analog Outputs | 1 (AO1: 0-20mA / 0-10V) |
| Discrete Inputs | 7 (6 programmable, 1 safety PWR) |
| Relay Outputs | 2 (R1: NO/NC; R2: NO) |
| Communication Ports | CANopen (SUB-D 9), Modbus (2x RJ45) |
| Degree of Protection (IP) | IP20 (upper part, standard), configurable to IP21, IP41, IP54 with kits |
| Operating Temperature | -10…50 °C (14…122 °F) without derating; 50…60 °C (122…140 °F) with derating |
| Dimensions (H x W x D) | 400 x 230 x 213 mm (15.7 x 9.06 x 8.4 in) |
| Net Weight | 22 kg (48.5 lb) |
| Standards & Certifications | CE, UL, CSA, C-tick, GOST, DNV, NOM |
| Product Status | Discontinued (Jan 1, 2017). End of Service: Oct 28, 2025. |
| Warranty | 18 Months |
