Schneider Electric EOCRDS3-60S / EOCRSS-60S EOCR Electronic Overcurrent Relay, 5...60 A, 220 V AC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Schneider Electric EOCRDS3-60S is a high-performance electronic overcurrent protection relay engineered to safeguard critical industrial motors and electrical power circuits. Featuring a robust 5 to 60 A adjustment range, a dedicated 4...20 mA analog output, and an integrated 7-segment LED display, this unit delivers precise diagnostic visibility and advanced load monitoring capabilities. With comprehensive onboard protections against overload, phase loss, phase reversal, and locked rotor conditions, it is an essential component for maximizing equipment lifecycle and ensuring reliable operational uptime in demanding enterprise automation environments.
| Product ID (MPN) | EOCRDS3-60S |
| Secondary ID / Device Short Name | EOCRSS-60S |
| Protection Adjustment Range | 5...60 A |
| Rated Supply Voltage (Us) | 220 V AC (50...60 Hz) |
| Rated Operational Voltage (Ue) | Up to 690 V AC |
| Contacts Type & Composition | 1 NO + 1 NC (OL) |
| Protection Type | Overload, Phase Loss, Phase Reverse, Locked Rotor, Phase Unbalance (50%) |
| Display Type | 7 Segments LED |
| Analogue Output Range | 4...20 mA |
| Time Delay Type | O-Time: 0.3, 1...30 s (definite); D-Time: 1...120 s (definite) |
| Reset Configuration | Manual reset / Electrical (0...1 s by interruption of power supply) |
| Power Consumption | 3 W per relay |
| Mounting Support | 35 mm DIN rail / Panel mount |
| IP Degree of Protection | IP20 (conforming to IEC 60529) |
| Dimensions (H x W x D) | 71 mm x 70 mm x 68 mm |
