Schneider Electric EOCRSS-05S EOCR Series Electronic Overcurrent Relay, 0.5-6A, 220V AC
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Schneider Electric EOCRSS-05S is an EOCR-series electronic overcurrent protection relay for monitoring and protecting motor loads. It provides an adjustable current range of 0.5–6 A, operates from a 220 V AC supply, and includes a 7-segment LED display for status indication.
| Brand | Schneider Electric |
| Manufacturer Part Number | EOCRSS-05S |
| Series | EOCR |
| Product Type | Electronic overcurrent protection relay |
| Protection Adjustment Range | 0.5–6 A |
| Tripping Threshold | 0.5–6 A |
| Rated Supply Voltage | 220 V AC, 50–60 Hz |
| Protection Functions | Overload, phase loss, phase reversal, locked rotor, and 50% phase unbalance |
| Contact Configuration | 1 NO + 1 NC |
| Reset Type | Manual reset or electrical interruption, 0–1 s |
| Display Type | 7-segment LED |
| Mounting Support | 35 mm DIN rail or panel mounting |
| Dimensions | 71 x 70 x 68 mm |
Typical applications: Motor control centers, automation panels, industrial machinery, and motor protection circuits requiring adjustable overcurrent and phase-fault monitoring.
Apexon Supply provides B2B sourcing and replacement support for Schneider Electric EOCRSS-05S. Verify the 0.5–6 A adjustment range, 220 V AC supply, protection functions, contact configuration, mounting method, and dimensions before replacement.
Send the MPN, required quantity, motor ratings, and application requirements to request a B2B quote and technical alignment support.
