Schneider Electric LC1D65AF7C TeSys Deca Contactor, 3-Pole, 65A, 110VAC - Pack of 2
Regular price
$90.00 USD
Regular price
Sale price
$90.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Schneider Electric LC1D65AF7C TeSys Deca Contactor is a robust solution designed for various electrical applications, supporting up to 65A with a control voltage of 110VAC. Ideal for both inductive and resistive loads, it offers reliability and efficiency in a compact form factor with EverLink terminals.
| Product Series | TeSys Deca |
| Product Type | Contactor |
| Number of Poles | 3P |
| Rated Operational Voltage [Ue] | <= 690 V AC, <= 300 V DC |
| Rated Operational Current [Ie] | 65 A (<= 440 V AC, AC-3) |
| Control Circuit Voltage [Uc] | 110 V AC 50/60 Hz |
| Motor Power (kW) | 37 kW (<= 500 V AC, AC-3) |
| Thermal Current [Ith] | 80 A (<= 60°C, Power Circuit) |
| Short-time Withstand Current [Icw] | 520 A for 10s (<= 40°C, Power Circuit) |
| Insulation Voltage [Ui] | 690 V (Power Circuit) |
| Impulse Withstand Voltage [Uimp] | 6 kV |
| Mechanical Durability | 6 Mcycles |
| Electrical Durability | 1.5 Mcycles (65 A, AC-3, <= 440 V) |
| Connection Capability | EverLink BTR Terminals, 1-35 mm² |
| Protection Rating | IP2X |
| Dimensions (HxWxD) | 122 x 55 x 120 mm |
| Net Weight | 0.86 kg |
