Schneider Electric TM2AVO2HT Analog Output Module, 2x Voltage Outputs (+/-10V), 11-bit + Sign, for Modicon M238 & Twido, 24VDC, Screw Terminal
Regular price
$580.00 USD
Regular price
Sale price
$580.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Schneider Electric TM2AVO2HT is an analog output module for Modicon M238, Twido, and Advantys OTB controllers. It provides 2 voltage outputs in the range of +/-10 V with 11-bit plus sign resolution. Designed for precise control applications, it features fast conversion time, high accuracy, photocoupler isolation, and a compact form factor suitable for DIN rail mounting.
- 2-Channel Analog Voltage Output Module (+/-10 V)
- High 11-bit + Sign Resolution (9.8 mV LSB)
- High Accuracy: ±0.5% of Full Scale at 25°C
- Fast Conversion Time: 2 ms + 1 controller cycle
- Photocoupler Isolation (2500 V) between Channels and Internal Logic
- Compact Design for DIN Rail Mounting (23.5 mm wide)
- Compatible with Modicon M238, Twido, and Advantys OTB
- Single Removable Screw Terminal Block for Easy Wiring
| Product ID | TM2AVO2HT |
| EAN / GTIN | 3595863996364 |
| Brand | Schneider Electric |
| Range | Modicon M238 logic controller |
| Product Type | Analog Output Module |
| Analog Output Number | 2 |
| Analog Output Type | Voltage +/- 10 V |
| Analog Output Resolution | 11 bits + sign |
| LSB Value | +/- 9.8 mV |
| Load Impedance | ≤ 3000 Ω (Resistive) |
| Conversion Time | 2 ms + 1 controller cycle time |
| Measurement Error | ±0.5 % of full scale at 25 °C |
| Total Error | ±1 %FS |
| [Us] Rated Supply Voltage | 24 V DC |
| Supply Voltage Limits | 19.2...30 V DC |
| Current Consumption | 60 mA @ 24 V DC (External), 60 mA @ 5 V DC (Internal) |
| Electrical Connection | 1 Removable Screw Terminal Block |
| Insulation | Photocoupler, 2500 V between I/O and internal logic |
| Dimensions (W x H x D) | 23.5 x 90 x 70 mm (0.9 x 3.5 x 2.8 in) |
| Net Weight | 0.085 kg (0.187 lb) |
| Range Compatibility | Modicon M238, Twido, Advantys OTB |
