Schneider Electric GV2ME07 TeSys Deca Motor Circuit Breaker, Thermal-Magnetic, 1.6–2.5 A
Regular price
$80.00 USD
Regular price
Sale price
$80.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Schneider Electric TeSys Deca GV2ME07 is a 3-pole thermal-magnetic motor circuit breaker for manual starting and dependable protection of motors up to 1.5 kW. Its 1.6 – 2.5 A adjustable range, push-button control and high short-circuit capacity ensure reliable operation in demanding industrial environments.
- Integrated thermal-magnetic trip for overload and short-circuit protection
- Adjustable thermal setting: 1.6 – 2.5 A
- Ultimate breaking capacity: 100 kA (230–500 V AC); 3 kA (690 V AC)
- Push-button ON/OFF with phase-failure sensitivity
- Compact 45 mm housing, DIN-rail or panel mount (IP20)
- Mechanical & electrical endurance: 100 000 cycles
| Product ID (MPN) | GV2ME07 |
| EAN / GTIN | 3389110343076 |
| Brand | Schneider Electric |
| Series / Range | TeSys Deca (GV2) |
| Product Type | Thermal-Magnetic Motor Circuit Breaker / Manual Starter & Protector |
| Poles | 3P |
| Trip Unit Technology | Thermal-magnetic |
| Thermal Setting Range | 1.6 – 2.5 A |
| Line Rated Current (In) | 2.5 A |
| Magnetic Trip Current | 39 A |
| Breaking Capacity (Icu) | 100 kA (230-500 V AC); 3 kA (690 V AC) |
| Rated Operational Voltage (Ue) | 690 V AC 50/60 Hz |
| Rated Insulation Voltage (Ui) | 690 V AC |
| Rated Impulse Withstand (Uimp) | 6 kV |
| Network Frequency | 50 / 60 Hz |
| Utilisation Category | Category A, AC-3 / AC-3e |
| Control Type | Push-button |
| Phase-Failure Sensitivity | Yes |
| Suitability for Isolation | Yes (IEC 60947-1) |
| Mechanical Durability | 100 000 cycles |
| Electrical Durability | 100 000 cycles (AC-3 415 V) |
| Power Dissipation per Pole | 2.5 W |
| Mounting | 35 mm DIN-rail clip or panel (adapter) |
| Connection Type / Size | Screw clamp 1 – 6 mm² (solid) / 1.5 – 6 mm² (flex) |
| Tightening Torque | 1.7 N·m |
| Width | 45 mm |
| Height | 89 mm |
| Depth | 78.5 mm |
| Net Weight | 0.26 kg |
| Colour | Dark grey |
| IP Rating | IP20 |
| IK Rating | IK04 |
| Ambient Temp (Operation) | -20 … 60 °C |
| Ambient Temp (Storage) | -40 … 80 °C |
| Standards | EN/IEC 60947-2, EN/IEC 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1 |
| Certifications | CCC, UL, CSA, EAC, ATEX, Lloyds, BV, RINA, DNV-GL, UKCA |
| Warranty | 18 months |
