Schneider Electric GV2ME08C TeSys Deca Motor Circuit Breaker, 2.5-4A Thermal Setting, 3P
Regular price
$40.00 USD
Regular price
Sale price
$40.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Schneider Electric GV2ME08C is a high-performance 3-pole thermal-magnetic motor circuit breaker from the TeSys Deca series, specifically engineered for the protection and isolation of AC motors. This push-button operated device provides essential short-circuit and overload protection for industrial motor applications with a thermal adjustment range of 2.5 to 4 Amperes.
| Product ID (MPN) | GV2ME08C |
| Product Family | TeSys Deca / GV2 |
| Number of Poles | 3P |
| Thermal Protection Adjustment | 2.5...4 A |
| Magnetic Tripping Current | 51 A |
| Rated Operational Voltage (Ue) | 690 V AC 50/60 Hz |
| Breaking Capacity (Icu) | 100 kA @ 400/415 V AC |
| Control Type | Push-button |
| Rated Impulse Withstand Voltage | 6 kV |
| Mechanical Durability | 100,000 Cycles |
