Schneider Electric LC1D09 TeSys Deca Contactor, 3P, 9 A AC-3 4kW, 1NO+1NC Aux
Regular price
$15.00 USD
Regular price
Sale price
$15.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Schneider Electric LC1D09 is a premium 3-pole contactor from the world-renowned TeSys Deca series, designed for high-performance motor control and industrial automation. Featuring integrated 1NO+1NC auxiliary contacts and a compact 45mm width, it provides superior electrical durability and safety for motor applications up to 4kW at 400V, making it the industry standard for precision electrical switching.
| Product ID (MPN) | LC1D09 |
| Rated Operational Current (Ie) | 9 A (AC-3, <= 440 V) / 25 A (AC-1, <= 440 V) |
| Motor Power (kW) | 4 kW at 380/400 V AC 50/60 Hz |
| Pole Configuration | 3P (3 NO) |
| Auxiliary Contacts | 1 NO + 1 NC |
| Control Coil Voltage | Available in AC 24V, 36V, 110V, 220V, 380V (50/60 Hz) |
| Mounting Base | 35 mm DIN Rail or Plate Mounting |
| Overvoltage Category | III conforming to IEC 60664 |
| Safety Certification | UL, CSA, CCC, CE, Marine (DNV-GL, RINA) |
