Schneider Electric LC1D128 / LC1D128MDC TeSys D 4-Pole Contactor, 25A AC-1, 220V DC Coil
Regular price
$45.00 USD
Regular price
Sale price
$45.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Schneider Electric LC1D128 TeSys D series is a versatile 4-pole contactor (2 NO + 2 NC) designed for efficient switching of resistive loads up to 25A. Available in multiple coil configurations including M7C (AC 220V) and MDC (DC 220V), this series provides high-reliability control for industrial heating, lighting, and power distribution systems with integrated auxiliary contacts.
| Product ID (MPN) | LC1D128 |
| Available Coil Variants | M7C (220VAC), F7C (110VAC), E7C (48VAC), B7C (24VAC), MDC (220VDC), FDC (110VDC), EDC (48VDC), BDC (24VDC) |
| Pole Configuration | 4P (2 NO + 2 NC) |
| Rated Operational Current (Ie) | 25 A (AC-1) at <= 440 V AC |
| Rated Operational Voltage | 690 V AC 25...400 Hz |
| Auxiliary Contacts | 1 NO + 1 NC (Standard) |
| Mechanical Durability | 15 Mcycles (AC) / 30 Mcycles (DC) |
| Standard Compliance | IEC 60947-4-1, UL 508, CSA C22.2 |
