Schneider Electric LC1D38 TeSys Deca Contactor, 3P, 38A AC-3 18.5kW, 1NO+1NC Aux
Regular price
$20.00 USD
Regular price
Sale price
$20.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Schneider Electric LC1D38 is a premium 3-pole contactor from the TeSys Deca series, engineered for high-efficiency switching and robust motor control in demanding industrial environments. Designed for motors up to 18.5kW at 400V, this contactor features advanced EverLink terminal technology for consistent tightening torque and 98% contact reliability, ensuring maximum uptime and safety for your electrical control circuits.
| Product ID (MPN) | LC1D38 |
| Rated Operational Current (Ie) | 38 A (AC-3, <= 440 V) / 50 A (AC-1, <= 440 V) |
| Motor Power (kW) | 18.5 kW at 380/400 V AC 50/60 Hz |
| Pole Configuration | 3P (3 NO) |
| Auxiliary Contacts | 1 NO + 1 NC |
| Control Voltage Options | AC 24V, 36V, 110V, 220V, 380V (50/60 Hz) |
| Rated Insulation Voltage (Ui) | 690 V conforming to IEC 60947-4-1 |
| Electrical Durability | 1.4 Mcycles 38 A AC-3 at Ue <= 440 V |
| Mounting Type | DIN Rail or Plate Mounting |
