Schneider Electric LC1D50AF7C TeSys Deca Contactor, 3 Pole (3NO), 50A, 110 VAC - Pack of 2
Regular price
$100.00 USD
Regular price
Sale price
$100.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview
The Schneider Electric LC1D50AF7C is a TeSys Deca contactor suitable for applications with non-inductive or slightly inductive loads and resistive furnaces. It supports AC loads with a power factor of 0.95 or higher, featuring a 3-pole (3NO) configuration and a control circuit voltage of 110 V AC.
Key Features
- TeSys Deca Series
- 3 Pole (3NO)
- Rated Current: 50A
- Control Voltage: 110 V AC, 50/60Hz
- Robust and reliable design
Specifications
| Product Series | TeSys Deca |
| Poles | 3P |
| Main Circuit Voltage | <= 690 V AC |
| Rated Current [Ie] | 50 A |
| Control Circuit Voltage | 110 V AC 50/60 Hz |
| Auxiliary Contacts | 1 NO + 1 NC |
| Electrical Life | 1.2 Mcycles |
| Mechanical Life | 6 Mcycles |
| Operating Frequency | 3600 operations/hour |
| Dimensions (HxWxD) | 122mm x 55mm x 120mm |
| Net Weight | 0.855 Kg |
| Mounting | Rail mount, Base mount |
