The Schneider Electric LC1N0601 contactor family includes LC1N0601B5N, LC1N0601CC5N, LC1N0601F5N, LC1N0601M5N, and LC1N0601Q5N. These Easy TeSys Control contactors have three normally open main poles, a 6 A AC-3 rating at up to 440 V AC, and one normally closed auxiliary contact. The complete model number identifies the required 50 Hz AC coil voltage.
24 V AC Coil Model
LC1N0601B5N, 50 Hz
36 V AC Coil Model
LC1N0601CC5N, 50 Hz
110 V AC Coil Model
LC1N0601F5N, 50 Hz
220 V AC Coil Model
LC1N0601M5N, 50 Hz
380 V AC Coil Model
LC1N0601Q5N, 50 Hz
Product Range
Easy TeSys Control
Rated Operational Current
6 A at up to 440 V AC, AC-3
Main Pole Configuration
3P, 3 NO
Auxiliary Contact
1 NC
Motor Power
2.2 kW at 380–400 V AC, 50/60 Hz
Rated Operational Voltage
Power circuit: up to 690 V AC, 50/60 Hz
Utilisation Categories
AC-1, AC-3, AC-4
These contactors are specified for motor control and resistive-load switching. Confirm the complete model number, coil voltage, rated current, pole configuration, and auxiliary contact arrangement against the original control circuit before replacement.
Apexon Supply provides B2B sourcing and replacement support for Schneider Electric LC1N0601 contactors, helping procurement teams compare the five coil-voltage variants and prepare an accurately identified RFQ.
Submit LC1N0601B5N, LC1N0601CC5N, LC1N0601F5N, LC1N0601M5N, or LC1N0601Q5N, together with the required quantity and application requirements, for procurement review. Most qualified RFQs receive a response or quote within 12 hours.
