The Schneider Electric LC1N1801 contactor family includes LC1N1801B5N, LC1N1801CC5N, LC1N1801F5N, LC1N1801M5N, and LC1N1801Q5N. These Easy TeSys Control contactors have a 3-pole configuration, an 18 A AC-3 rating at up to 440 V AC, and one normally closed auxiliary contact. The complete model number identifies the required 50 Hz AC coil voltage.
24 V AC Coil Model
LC1N1801B5N, 50 Hz
36 V AC Coil Model
LC1N1801CC5N, 50 Hz
110 V AC Coil Model
LC1N1801F5N, 50 Hz
220 V AC Coil Model
LC1N1801M5N, 50 Hz
380 V AC Coil Model
LC1N1801Q5N, 50 Hz
Product Range
Easy TeSys Control
Pole Configuration
3P
Rated Operational Current
18 A at up to 440 V AC, AC-3
Auxiliary Contact
1 NC
Terminal Type
Multi-standard screw terminals
Schneider Electric identifies these contactors for essential motor-control and efficient AC-3e motor-switching applications. The range is also certified under EN/IEC 60335 for household and HVAC applications.
Apexon Supply provides B2B sourcing and replacement support for Schneider Electric LC1N1801 contactors. Procurement teams can compare the listed coil-voltage variants and confirm the complete model number against the existing control circuit.
Submit LC1N1801B5N, LC1N1801CC5N, LC1N1801F5N, LC1N1801M5N, or LC1N1801Q5N, together with the required quantity and application requirements, for RFQ support. Most qualified RFQs receive a response or quote within 12 hours.
