The Schneider Electric LC1N2501 contactor family includes LC1N2501B5N, LC1N2501CC5N, LC1N2501F5N, LC1N2501M5N, and LC1N2501Q5N. These Easy TeSys Control contactors have three normally open main poles, a 25 A AC-3 rating at up to 440 V AC, and one normally closed auxiliary contact. The complete model number identifies the required 50 Hz AC coil voltage.
24 V AC Coil Model
LC1N2501B5N, 50 Hz
36 V AC Coil Model
LC1N2501CC5N, 50 Hz
110 V AC Coil Model
LC1N2501F5N, 50 Hz
220 V AC Coil Model
LC1N2501M5N, 50 Hz
380 V AC Coil Model
LC1N2501Q5N, 50 Hz
Product Range
Easy TeSys Control
Rated Operational Current
25 A at up to 440 V AC, AC-3
Main Pole Configuration
3P, 3 NO
Auxiliary Contact
1 NC
Control Circuit Type
AC at 50 Hz
Terminal Type
Multi-standard screw terminals
Schneider Electric identifies these contactors for essential motor-control and efficient AC-3e motor-switching applications, including household and HVAC equipment covered by EN/IEC 60335 certification. Confirm the complete model number and coil voltage against the original control circuit before replacement.
Apexon Supply provides B2B sourcing and replacement support for Schneider Electric LC1N2501 contactors. Procurement teams can compare the five coil-voltage variants and use the complete model number to support accurate technical alignment.
Submit LC1N2501B5N, LC1N2501CC5N, LC1N2501F5N, LC1N2501M5N, or LC1N2501Q5N, together with the required quantity and application requirements, for RFQ support. Most qualified RFQs receive a response or quote within 12 hours.
