Schneider Electric LC1N2510 EasyPact D3N Contactor, 3P, 25A AC-3 11kW, 1NO Aux

$20.00 USD

Sale Sold out

Shipping calculated at checkout.

Model B5N (AC24V) CC5N (AC36V) F5N (AC110V) M5N (AC220V) Q5N (AC380V)

Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)

The Schneider Electric LC1N2510 is a high-performance 3-pole contactor from the EasyPact D3N series, designed for motor control and resistive load switching in industrial environments. Engineered for reliability in standard applications up to 11kW (400V), this versatile contactor offers a balance of compact design and robust electrical endurance for modern automation panels.

Product ID (MPN)	LC1N2510
Rated Operational Current (Ie)	25 A (AC-3, <= 440 V) / 40 A (AC-1, <= 440 V)
Motor Power (kW)	11 kW at 380/400 V AC 50/60 Hz
Pole Configuration	3P (3 NO)
Auxiliary Contact	1 NO
Coil Voltage Options	AC24V (B5N), AC36V (CC5N), AC110V (F5N), AC220V (M5N), AC380V (Q5N)
Mounting Base	35 mm DIN Rail or Screw Mounting
Frequency	50/60 Hz
Standards	IEC 60947-4-1, GB/T 14048.4

View full details
