The Schneider Electric LC1N3801 family consists of Easy TeSys Control D3N 3-pole motor contactors with 3 NO main contacts and one built-in 1 NC auxiliary contact. This series page covers LC1N3801B5N, LC1N3801CC5N, LC1N3801F5N, LC1N3801M5N, and LC1N3801Q5N, with the complete MPN identifying the required 50 Hz AC coil voltage.
Series Reference
LC1N3801
LC1N3801B5N
24 V AC coil, 50 Hz
LC1N3801CC5N
36 V AC coil, 50 Hz
LC1N3801F5N
110 V AC coil, 50 Hz
LC1N3801M5N
220 V AC coil, 50 Hz
LC1N3801Q5N
380 V AC coil, 50 Hz
AC-3 Reference Rating
38 A at up to 440 V AC
Motor Power
18.5 kW at 380–400 V and 415–440 V AC, 50/60 Hz
Main Contacts
3P, 3 NO
Auxiliary Contact
1 NC
Utilisation Categories
AC-1, AC-3, AC-4
Power Circuit Voltage
Up to 690 V AC, 50/60 Hz
Rated Insulation Voltage
690 V
Mounting Support
DIN rail or plate
Dimensions
56 mm wide × 84 mm high × 86 mm deep
Degree of Protection
IP20
Typical applications include motor control and resistive-load switching under the stated utilisation categories. Verify the complete MPN, coil voltage, control frequency, duty rating, and auxiliary-contact requirement before selecting a replacement.
Apexon Supply provides B2B sourcing and replacement support for the Schneider Electric LC1N3801 contactor family, helping procurement and maintenance teams compare coil variants and align the selected MPN with existing control-panel requirements.
For RFQ support, submit the required quantity and complete MPN: LC1N3801B5N, LC1N3801CC5N, LC1N3801F5N, LC1N3801M5N, or LC1N3801Q5N. Most qualified RFQs receive a response or quote within 12 hours.
