The Schneider Electric LC1N50 contactor family includes LC1N50B5N, LC1N50CC5N, LC1N50F5N, LC1N50M5N, and LC1N50Q5N. These Easy TeSys Control contactors have three normally open main poles, a 50 A AC-3 rating at up to 440 V AC, and built-in 1 NO + 1 NC auxiliary contacts. The complete model number identifies the required 50 Hz AC coil voltage.
24 V AC Coil Model
LC1N50B5N, 50 Hz
36 V AC Coil Model
LC1N50CC5N, 50 Hz
110 V AC Coil Model
LC1N50F5N, 50 Hz
220 V AC Coil Model
LC1N50M5N, 50 Hz
380 V AC Coil Model
LC1N50Q5N, 50 Hz
Product Range
Easy TeSys Control
Rated Operational Current
50 A at up to 440 V AC, AC-3
AC-1 Operational Current
60 A at up to 440 V AC
Main Pole Configuration
3P, 3 NO
Auxiliary Contacts
1 NO + 1 NC
Motor Power
22 kW at 380–400 V AC, 50/60 Hz
Rated Operational Voltage
Power circuit: up to 690 V AC, 50/60 Hz
Mounting Support
Plate or DIN rail
These contactors are specified for essential motor-control, AC-3e motor-switching, household, and HVAC applications. Confirm the complete model number, coil voltage, rated current, pole configuration, and auxiliary contacts against the original control circuit before replacement.
Apexon Supply provides B2B sourcing and replacement support for Schneider Electric LC1N50 contactors, helping procurement teams compare the five coil-voltage variants and prepare an accurately identified RFQ.
Submit LC1N50B5N, LC1N50CC5N, LC1N50F5N, LC1N50M5N, or LC1N50Q5N, together with the required quantity and application requirements, for procurement review. Most qualified RFQs receive a response or quote within 12 hours.
