Schneider Electric LC1N65 EasyPact D3N AC Contactor, 65A, 3-Pole, 1NO+1NC Auxiliary, 30kW@380V
Regular price
$40.00 USD
Regular price
Sale price
$40.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Schneider Electric LC1N65 is a heavy-duty 3-pole AC contactor from the EasyPact D3N series, engineered for high-capacity motor control and industrial power switching up to 30kW. Featuring an integrated 1NO + 1NC auxiliary contact configuration and a robust chassis, this contactor provides exceptional electrical durability and reliable switching performance for large-scale industrial equipment and automation systems.
| Product ID (MPN) | LC1N65 |
| Product Series | EasyPact D3N |
| Rated Operational Current (Ie) | 65A (AC-3, 380/400V) |
| Rated Power (kW) | 30 kW @ 380/400V AC 50/60Hz |
| Pole Configuration | 3 Pole (3 NO Main Contacts) |
| Auxiliary Contacts | 1 NO + 1 NC (Integrated) |
| Coil Voltage Options | 24V, 36V, 110V, 220V, 380V AC |
| Installation | 35mm DIN Rail / Plate Mounting |
| Compliance Standards | IEC 60947-4-1, GB/T 14048.4 |
