The Schneider Electric LC1N80 contactor family covers five Easy TeSys Control models: LC1N80B5N, LC1N80CC5N, LC1N80F5N, LC1N80M5N, and LC1N80Q5N. Each model is a 3-pole contactor rated at 80 A at up to 440 V AC under AC-3 duty, with three normally open main poles and one normally open plus one normally closed auxiliary contact. The complete MPN identifies the required 50 Hz AC coil voltage.
24 V AC Coil Model
LC1N80B5N, 50 Hz
36 V AC Coil Model
LC1N80CC5N, 50 Hz
110 V AC Coil Model
LC1N80F5N, 50 Hz
220 V AC Coil Model
LC1N80M5N, 50 Hz
380 V AC Coil Model
LC1N80Q5N, 50 Hz
Product Range
Easy TeSys Control
Rated Operational Current
80 A at ≤440 V AC, AC-3
Main Pole Configuration
3P, 3 NO
Auxiliary Contacts
1 NO + 1 NC
Motor Power
37 kW at 380/400 V AC, 50/60 Hz
Rated Operational Voltage
Power circuit: ≤690 V AC, 50/60 Hz
These contactors are specified for motor control and resistive-load switching. Confirm the complete MPN, coil voltage, rated current, pole configuration, and auxiliary contacts against the original control circuit before replacement.
Apexon Supply provides B2B sourcing and replacement support for Schneider Electric LC1N80 contactors, helping procurement teams compare the five coil-voltage variants and confirm technical alignment with existing control-panel requirements.
Submit LC1N80B5N, LC1N80CC5N, LC1N80F5N, LC1N80M5N, or LC1N80Q5N, together with the required quantity and application requirements, for procurement review. Most qualified RFQs receive a response or quote within 12 hours.
