Schneider Electric LRN363N Easy TeSys Protect Thermal Overload Relay, 63-80A, Class 10A
Regular price
$50.00 USD
Regular price
Sale price
$50.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Schneider Electric LRN363N is a high-performance differential thermal overload relay from the Easy TeSys Protect range, specifically designed for dependable motor protection. This 63-80A rated component features phase failure sensitivity and integrated auxiliary contacts, ensuring robust operational safety in industrial control systems when paired with LC1N80...95 contactors.
| Product ID (MPN) | LRN363N |
| Thermal Protection Adjustment Range | 63...80 A |
| Thermal Overload Class | Class 10A conforming to IEC 60947-4-1 |
| Product Compatibility | LC1N80...95 |
| Network Type / Frequency | AC, 50...60 Hz |
| [Ue] Rated Operational Voltage | <= 690 V AC |
| Auxiliary Contact Composition | 1 NO + 1 NC |
| Phase Failure Sensitivity | Tripping current I 30% of Ir on one phase (IEC 60947-4-1) |
| Mounting Support | Under contactor; Plate or Rail with accessories |
| [Ui] Rated Insulation Voltage | 690 V (IEC 60947-4-1) |
| IP Degree of Protection | IP20 (IEC 60529) |
| Dimensions (H x W x D) | 54 mm x 70 mm x 113 mm |
