Nidec VRSF-5D-28HA22 Planetary Inline Gear Reducer, 1:5 Ratio, Frame D
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Nidec VRSF-5D-28HA22 is an ABLE VRSF Series planetary inline gear reducer with a 1:5 single-stage reduction ratio, frame size D, and 28HA22 motor mounting code. It uses helical-cut planetary gearing and an aluminum housing for precision servo and stepper motor applications.
| Product ID | VRSF-5D-28HA22 |
| Brand | Nidec |
| Series | ABLE VRSF Series |
| Gear Type | Planetary, helical cut |
| Reduction Ratio | 1:5, single stage |
| Frame Size | D |
| Motor Mounting Code | 28HA22 |
| Nominal Output Torque | 23.5 Nm |
| Maximum Acceleration Torque | 70.6 Nm |
| Nominal Input Speed | 3000 rpm |
| Maximum Input Speed | 5000 rpm |
| Efficiency | 90% |
| Torsional Rigidity | 6 Nm/arcmin |
| Standard Backlash | ≤ 15 arc-min |
| Permitted Radial Load | 1080 N |
| Permitted Axial Load | 539 N |
| Noise Level | ≤ 72 dB |
| Protection Class | IP65 |
| Housing Material | Aluminum |
Typical applications include precision servo and stepper motor systems, traveling axes, end-of-arm tooling, and industrial motion-control assemblies requiring inline planetary speed reduction.
Apexon Supply provides B2B sourcing and replacement support for the Nidec VRSF-5D-28HA22. Buyers should verify the ratio, frame size, motor mounting code, torque ratings, shaft loads, speed limits, and mechanical interface against the application requirements.
Send the MPN, required quantity, motor details, and application requirements to request a B2B quote and technical alignment review.
