SIBA 50 140 06.135 URZ Cylindrical Fuse-Link, 135A, 690V AC, aR, Ø 22x58mm (10 Pieces)
Regular price
$215.00 USD
Regular price
Sale price
$215.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SIBA 50 140 06.135 is a high-capacity URZ series cylindrical fuse-link engineered to provide ultra-rapid protection for industrial semiconductors and power electronics. Moving into the aR characteristic class for high-amperage applications, this 135A, 22x58mm component safely clearing short-circuit faults with a robust rated breaking capacity of 200 kA. Manufactured without a striker assembly and designed to meet stringent DIN, IEC, and VDE electrotechnical standards, it guarantees reliable deployment in demanding enterprise-grade switchgear systems.
| Product ID (MPN) | 50 140 06.135 |
| Product Series | URZ |
| Fuse Type | Cylindrical Fuse-Link |
| Rated Current | 135 A |
| Rated Voltage | 690 V AC |
| Operating Class | aR (> 100A Models) |
| Dimensions / Size | Ø 22 x 58 mm |
| Rated Breaking Capacity | 200 kA (AC) |
| Pre-Arcing I²t-Value | 3,500 A²s |
| Total I²t-Value | 25,000 A²s (@ AC 660 V) |
| Power Loss | 26.0 W |
| Indicator / Striker | Without striker |
| Approvals & Standards | DIN EN 60269-4, IEC 60269-4, VDE 0636-4 |
| Weight | 0.06 kg |
