SICK TMM88B-AKC090 Dual-Axis Inclination Sensor, ±90°, 4–20 mA
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The SICK TMM88B-AKC090 is a dual-axis inclination sensor from the TMS/TMM88 series, identified by SICK part number 1073791. It provides a ±90° measuring range, 0.01° resolution, and dual 4–20 mA current outputs for industrial inclination measurement and monitoring.
| Manufacturer | SICK |
| Model | TMM88B-AKC090 |
| SICK Part Number | 1073791 |
| Series | TMS/TMM88 |
| Number of Axes | 2 |
| Measuring Range | ±90° |
| Resolution | 0.01° |
| Static Measurement Accuracy | Up to ±60°: typically ±0.1°, maximum ±0.2°; up to ±80°: typically ±0.2°, maximum ±0.4° |
| Sampling Rate | 80 Hz |
| Output | 4–20 mA current output |
| Load Resistance | ≤850 Ω at 24 V supply |
| Supply Voltage | 17–35 V DC |
| Electrical Connection | M12 male connector, 5-pin |
| Dimensions | 58 mm × 90 mm × 31 mm |
| Housing Material | Aluminum |
| Enclosure Rating | IP65 and IP67 according to IEC 60529 |
| Operating Temperature | −40°C to +80°C |
| Configuration | Programmable and configurable using PGT-12-Pro |
| Installation Notes | M12 pin 5 provides the TEACH input for zero-point setting |
Typical applications include two-axis inclination measurement, angular position monitoring, and machine orientation feedback in industrial systems designed for 4–20 mA current inputs.
Apexon Supply provides B2B sourcing, replacement sourcing, and technical alignment support for the SICK TMM88B-AKC090. Compare the measuring range, output, supply voltage, connector pinout, dimensions, and environmental ratings with the installed sensor and control input before replacement.
Send the MPN, SICK part number 1073791, required quantity, and application requirements to request a B2B quote. Most qualified RFQs receive a response or quote within 12 hours.
