Siemens 6ES7288-1ST40-0AA0 SIMATIC S7-200 SMART CPU ST40 PLC, 24 DI / 16 DO Transistor, 24V DC
Regular price
$300.00 USD
Regular price
Sale price
$300.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Siemens SIMATIC S7-200 SMART CPU ST40 is a high-performance compact PLC designed for the demanding requirements of the Chinese and emerging industrial markets. Featuring high-speed processing and integrated Ethernet and RS485 interfaces, this CPU provides a cost-effective solution for small to medium-scale automation tasks requiring precise transistor control and robust data handling.
| Product ID (MPN) | 6ES7288-1ST40-0AA0 |
| Number of Digital Inputs | 24; 24 V DC |
| Number of Digital Outputs | 16; Transistor |
| Supply Voltage | 24 V DC (20.4 to 28.8 V DC) |
| Memory Size | 24 kbyte Program memory / 16 kbyte User data |
| CPU Processing Time | 150 ns / bit operation |
| Integrated Interfaces | 1x Ethernet (RJ45), 1x RS 485 |
| High-Speed Counters | 4 HSC at 200 kHz (Single) / 2 HSC at 100 kHz (A/B phase) |
| Degree of Protection | IP20 |
| Dimensions (W x H x D) | 125 x 100 x 81 mm |
