Siemens 6ES7331-1KF02-0AB0 SIMATIC S7-300 Analog Input SM 331 Module, 8 AI, 13-bit Resolution, Isolated
Regular price
$320.00 USD
Regular price
Sale price
$320.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Siemens 6ES7331-1KF02-0AB0 is a high-precision SIMATIC S7-300 analog input module (SM 331) designed for versatile data acquisition in industrial automation. This isolated 8-channel module supports a wide array of measurement types including voltage, current, resistance, and temperature (Pt100, Ni100, Ni1000), featuring a 13-bit resolution and a 66ms conversion time to ensure accurate signal processing in enterprise-level PLC systems.
| Product ID (MPN) | 6ES7331-1KF02-0AB0 |
| Number of Analog Inputs | 8 |
| Resolution | 13 bit (including sign) |
| Input Ranges (Voltage) | ±1V, ±5V, ±10V, 1-5V, 0-10V |
| Input Ranges (Current) | ±20mA, 0-20mA, 4-20mA |
| Supported RTDs | Pt100, Ni100, Ni1000, LG-Ni1000 |
| Conversion Time | 66 ms / 55 ms (parameterizable) |
| Potential Separation | Yes; between channels and backplane bus |
| Required Front Connector | 40-pin |
| Dimensions (W x H x D) | 40 x 125 x 117 mm |
