Siemens 6ES7332-5HF00-0AB0 SIMATIC S7-300 Analog Output SM 332 Module, 8 AO, 11/12-bit Resolution, isolated
Regular price
$300.00 USD
Regular price
Sale price
$300.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Siemens 6ES7332-5HF00-0AB0 is a high-density SIMATIC S7-300 analog output module (SM 332) designed for precise actuator control in complex automation environments. This isolated 8-channel module supports universal voltage (±10V) and current (4-20mA) ranges with 12-bit resolution, and is specifically engineered to support removing and inserting during operation when used with an active backplane bus, ensuring maximum system uptime.
| Product ID (MPN) | 6ES7332-5HF00-0AB0 |
| Number of Analog Outputs | 8 |
| Resolution | 11/12 bit (parameterizable) |
| Output Ranges (Voltage) | 0 to 10 V, 1 to 5 V, ±10 V |
| Output Ranges (Current) | 0 to 20 mA, ±20 mA, 4 to 20 mA |
| Conversion Time | 0.8 ms per channel |
| Short-circuit Protection | Yes (max. 25 mA current) |
| Potential Separation | Yes (between channels and backplane bus) |
| Front Connector | 40-pin |
| Dimensions (W x H x D) | 40 x 125 x 117 mm |
