Siemens 6SL3300-7TE35-0AA0 SINAMICS S120 Pre-Charging Board, 380-480V AC, Frame Size GI
Regular price
$2,200.00 USD
Regular price
Sale price
$2,200.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Siemens 6SL3300-7TE35-0AA0 is a high-performance pre-charging board designed for the SINAMICS S120 chassis-format modular drive system. Optimized for enterprise-level motor control and power conversion applications, this GI frame size component ensures controlled DC link capacitance charging and robust short-circuit protection in demanding industrial environments.
| Product ID (MPN) | 6SL3300-7TE35-0AA0 |
| Product Series | SINAMICS S120 |
| Line Voltage | 3-Phase 380 - 480 V AC |
| DC Link Capacitance | 76,800 µF |
| Frame Size | GI |
| Short-circuit Strength | 8,000 A |
| Power Loss (400V/50Hz) | 3.9 kW |
| Type of Cooling | Internal Air Cooled (0.47 m³/s) |
| Degree of Protection | IP20 / UL Open Type |
| Dimensions (W x H x D) | 325 mm x 1,533 mm x 544 mm |
| Conductor Connection | Flat connector (M10 screw), Max 185 mm² |
