SINOFUSE EV315-H-3EB20A EV315 Series Bolt-Connected Fuse, 500V, 20A
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV315-H-3EB20A is an EV315 Series road vehicle fuse rated at 20A and 500V DC/AC. This H-3EB variant uses a single pin plug-in mounting configuration and has a verified pre-arcing I²t of 83 A²s, clearing I²t of 256 A²s, and power loss of 4 W.
| Part Number | EV315-H-3EB20A |
| Size | H-3EB |
| Rated Voltage | DC/AC 500V |
| Rated Current | 20A |
| Protection Category | EV |
| DC Breaking Capacity | 20kA, time constant 2±0.5ms |
| AC Breaking Capacity | 20kA, COSΦ=0.7-0.8 |
| Pre-arcing I²t | 83 A²s |
| Clearing I²t | 256 A²s |
| Power Loss | 4 W |
| Color | Yellow |
| Weight | 10.3±1.5 g |
| Mounting | Single pin plug-in |
| Standards | ISO8820, JASO D622, GB/T31465 |
| Compliance | RoHS Compliant |
Typical applications: The EV315 series is specified for short-circuit and backup protection of EV drive power, power conversion systems, energy storage and power batteries, energy storage capacitors, inverter controllers, chargers, wires, and other vehicle devices and equipment.
Apexon Supply provides B2B sourcing and replacement support for Sinofuse EV315-H-3EB20A, helping procurement teams review verified specifications and confirm technical alignment for replacement requirements.
Send EV315-H-3EB20A, required quantity, and application requirements to request a B2B quote. Most qualified RFQs receive a response or quote within 12 hours.
