Sinofuse EV315-H-3EB15A EV315 Series Electric Vehicle Fuse, 500VDC, 15A
Regular price
$20.00 USD
Regular price
Sale price
$20.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV315-H-3EB15A is an EV315 Series fuse for road-vehicle electrical protection applications including electric vehicle drive power systems, power conversion systems, energy storage, traction batteries, chargers, conductors, and vehicle electrical equipment. The uploaded EV315 series datasheet verifies 500VDC operation, 15A current rating data, RoHS compliance, and road-vehicle environmental suitability for short-circuit, overload, and backup protection.
| Product ID (MPN) | EV315-H-3EB15A |
| Series | EV315 Series |
| Product Category | Electric vehicle fuse / road-vehicle bolt-connected fuse |
| Rated Voltage | 500VDC |
| Rated Current | 15A |
| Breaking Capacity | 10kA for 10A–40A ratings |
| Time Constant | 2 ± 0.5ms |
| Pre-Arcing I²t | 38A²s for 15A EV315 3E rating |
| Total Clearing I²t | 128A²s for 15A EV315 3E rating |
| Power Loss | 3.6W for 15A EV315 3E rating |
| Color Code | Blue for 15A EV315 3E rating |
| Reference Standards | Performance reference: JASO D622; environmental reliability: ISO8820, JASO D622, GB/T31465 |
| Compliance | RoHS compliant |
| Recommended Continuous Current | Not more than 80% of rated current |
| Application Notes | Designed for short-circuit, overload, and backup protection in electric vehicle drive power systems, power conversion systems, energy storage, batteries, capacitors, inverters, chargers, conductors, and vehicle equipment |
