Sinofuse EV315-H-3EB30A EV315 Series Electric Vehicle Fuse, 500VDC, 30A
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
The Sinofuse EV315-H-3EB30A is an EV315 Series road vehicle fuse for EV circuit protection, rated at 30A and 500V DC. This H-3EB variant uses a single-pin plug-in mounting design and has a verified pre-arcing I²t of 333 A²s, clearing I²t of 1025 A²s, and power loss of 6 W.
| Part Number | EV315-H-3EB30A |
| Size | H-3EB |
| Rated Voltage | DC/AC 500V |
| Rated Current | 30A |
| Protection Category | EV |
| DC Breaking Capacity | 20kA, time constant 2±0.5ms |
| AC Breaking Capacity | 20kA, COSΦ=0.7-0.8 |
| Pre-arcing I²t | 333 A²s |
| Clearing I²t | 1025 A²s |
| Power Loss | 6 W |
| Color | Green |
| Weight | 10.3±1.5 g |
| Mounting | Single pin plug-in |
| Standards | ISO8820, JASO D622, GB/T31465 |
| Compliance | RoHS Compliant |
Typical applications: The EV315 series is specified for short-circuit and backup protection of EV drive power, power conversion systems, energy storage and power batteries, energy storage capacitors, inverter controllers, chargers, wires, and other vehicle devices and equipment.
Apexon Supply provides B2B sourcing and replacement support for Sinofuse EV315-H-3EB30A, helping procurement teams review verified specifications and confirm technical alignment for replacement requirements.
Send EV315-H-3EB30A, required quantity, and application requirements to request a B2B quote. Most qualified RFQs receive a response or quote within 12 hours.
